OUR
TOOLING
CAPACITIES


WE HAVE A BROAD RANGE OF TECHNOLOGIES AT OUR DISPOSAL.
MODERN CNC MACHINING CENTRES,
3 AND 5-AXIS MILLING, CNC TURNING MACHINES
FOR PIECE PRODUCTION AND SERIAL PRODUCTION


You can download our complete machinery list here


Everyone needs quality tools and the necessary know-how to do their job. The quality of the resulting product always depends on the symbiosis of this relationship, which is why we continue to modernise and expand our tooling capacities. The combination of a qualified operator and tooling capacities creates all the necessary prerequisites to deliver a high degree of precision in our products.





DESIGN
AND TECHNOLOGY


OUR DESIGNERS AND TECHNOLOGISTS USE THE FOLLOWING PROGRAMS:

Our main supplier of software solutions for CNC machining.


CAD: Autodesk Inventor, AutoCAD
CAM: PowerMil, Fusion360



SEPARATION
OF MATERIALS


BAND SAWS

BOMAR ERGONOMIC 320.250 DGS
PEGAS-POPULAR 230 PLUS GSH


CIRCULAR SAW

BOMAR - AL 500 semi-automatic




CHIP
MACHINING


5-AXIS CNC MACHINING CENTRES


GROB 550

table size: Ø 800mm, travel X/Y/Z (mm): 800/1020/1020
accuracy: 0.006 mm, Max. permissible loading weight: 700 kg


GROB 350

table size: Ø 600 mm, travel X/Y/Z (mm): 600/855/750
accuracy: 0.006 mm, Max. permissible loading weight: 400 kg


GROB 350/pallet changer

table size: 400/500 mm, travel X/Y/Z (mm): 600/770/805
accuracy: 0.006 mm, Max. permissible loading weight: 338 kg


DMG MORI DMF 180 | 7

table size (mm): Ø750, 2100/700, travel X/Y/Z (mm): 1800/700/700
accuracy: 0.010 mm, Max. permissible loading weight: 1500 kg


FANUC ROBODRILL D21LiB5

table size: 850/410 mm, travel X/Y/Z (mm): 700/400/330
accuracy: 0,004 mm, Max. permissible loading weight: 300 kg


3-AXIS CNC MACHINING CENTRES


PINNACLE-PK-VMC 1000S

table size: 1200/600 mm, travel X/Y/Z (mm): 1020/610/610
accuracy: 0.010 mm, Max. permissible loading weight: 850 kg


PINNACLE-PK-VMC 1100S

table size: 1300/600 mm, travel X/Y/Z (mm): 1140/610/610
accuracy: 0.010mm, Max. permissible loading weight: 850 kg


PINNACLE-VMC 1160

table size: 1300/600 mm, travel X/Y/Z (mm): 1140/610/610
accuracy: 0.010 mm, Max. permissible loading weight: 850 kg


HWACHEON-Vesta 1000

table size: 1100/500 mm, travel X/Y/Z (mm): 1.000/550/500
accuracy: 0.010 mm, Max. permissible loading weight: 700 kg


TURNING MACHINES:


TAKISAWA-TS4000YS

Max. turning diameter: Ø 370 mm
Max. running diameter over carriage: Ø 600 mm
Travel X/Z: 267/840 mm, Max. rod diameter: Ø 82 mm


COLCHESTER – TORNADO T6MS

Max. turning diameter: Ø 220 mm
Max. running diameter over carriage: Ø 440 mm
Travel X/Z: 210/170 mm, Max. rod diameter: Ø 54 mm


LEADW EL L-LTC 25-BLM

Max. turning diameter: Ø 305 mm
Max. running diameter over carriage: Ø 680 mm
Travel X/Z: 235+20/1090 mm, Max. rod diameter: Ø 85 mm


HWACHEON-CUTEX160BMC

Max. turning diameter: Ø 260 mm
Max. running diameter over carriage: Ø 550 mm
Travel X/Z:170/335 mm, Max. rod diameter: Ø 51 mm


SU-18

Max. turning diameter: Ø 215 mm
Max. running diameter over carriage: Ø 380 mm
Max. rod diameter: Ø 41 mm



QUALITY
CONTROL


Carl-Zeiss – CONTURA G2


measurement range 1000/1200/600 mm
measurement deviation: 1.8+L/300
Max. permissible loading weight: 1150 kg


MAHR - MARFSURF ST 500


Feed length ( in the axis X) 1 mm to 120 mm
Measurement range (in the Z axis):
50 mm for tracking arm 350 mm
25 mm for tracking arm 175 mm


TRIMOS – HEIGHT GAUGE V4


Measuring range: 407 mm
Max. Resolutions: 0.001 (0.00005) mm


KEYENCE IM-8200


High-precision measurement mode:
125 × 125 mm
Wide-field measurement mode:
200 × 200 mm (4× R50)





WELDING


MIG / MAGATIG / WIG WELDING SYSTEMS


MIG/MAG Fronius TPS 4000 - Trans Puls Synergic 4000
TIG/WIG Fronius TRANS tI G1750 Puls G/F
Compact 2295 - MIG/MAG



ASSEMBLY


MODERN TECHNOLOGY FOR
MECHANICAL, ELECTRICAL,
PNEUMATIC AND HYDRAULIC ASSEMBLY.


EElectric thread cutter – MOSQUITO 300 VH E
(vertical/horizontal) – ROSCAMAT


Blasting machine – DUKE 9080 – WISTA
